SR5シリーズ ステンレス製二段圧力調整器

ホーム / 製品 / ステンレス製圧力調整器 / SR5シリーズ ステンレス製二段圧力調整器

SR5シリーズ ステンレス製二段圧力調整器

SR5は2つの減圧室を1台に集約し、2段ダイヤフラム減圧構造の採用により、単段減圧器特有の「入口圧力変動」の問題を徹底的に解決しました。シリンダー内のガスが徐々に減り、圧力が継続的に低下するため、SR5 の 2 段階補償機構により、一貫した出力圧力が保証されます。この製品は、入口と出口の両方の状態を同時に監視する明確なデュアルダイヤルディスプレイを備えています。本体は、さまざまな予算や動作条件に合わせて、316L ステンレス鋼または銅メッキ素材からお選びいただけます。重量は 1.4kg と 2 段構造としては軽量で、構造強度を確保しながら、狭い分析キャビネット内へのパネルの設置が容易です。

  • 説明
  • お問い合わせ

シリーズ

ボディポート

入口圧力

出口圧力

ゲージ

インレットコネクタ

コンセントコネクタ

オプション

SR5

M

D

G

G

00

00

P

SR5L

(316L)

SR5B

(電気銅めっき)

M

Q

D:3000psi

F:500psi

G:0-250psi

1:0-100psi

K:0-50psi

L:0-25psi

Q:30"HgVac-30psi

S:30"HgVac-60psi

T:30"HgVac-100psi

U:30'HgVac-200psi

G:MPa表

P: psi/バーテーブル

W:圧力計なし

00:1/4"NPT(F)

01:1/4"NPT(M)

23:CGA330

24:CGA350

27:CGA580

28:CGA660

30;CGA590

52:G5/8'-RH(F)

63:W21.8-14RH(F)

64:W21.8-14LH(F)

他の形式のコネクタも選択可能です

00:1/4"NPT(F)

01:1/4"NPT(M)

10: 1/8 インチカードスリーブコネクタ

11: 1/4 インチカードスリーブコネクタ

12: 3/8 インチカードスリーブコネクタ

15: 6mmカードスリーブコネクタ

16: 8mmカードスリーブコネクタ

74;M8x1RH(M)

他の形式のコネクタも選択可能です

P:パネル取り付け

R:安全弁

N:ニードルバルブ

D: ダイヤフラムバルブ
