SR1シリーズ ステンレス製小流量圧力調整器

ホーム / 製品 / ステンレス製圧力調整器 / SR1シリーズ ステンレス製小流量圧力調整器

SR1シリーズ ステンレス製小流量圧力調整器

SR1は精密一段ダイヤフラム減圧構造を採用しており、高性能ステンレスダイヤフラムによる圧力伝達により極めて安定した出力圧力を確保します。さまざまな高純度ガス、腐食性ガス、有毒ガスにも安心して対応できます。バルブ本体は高級 316L ステンレス鋼、シートは PCTFE または PTFE、ダイヤフラムはハステロイまたは 316L ステンレス鋼で作られています。この高度な材料の組み合わせにより、-40 °C ~ 74 °C の過酷な温度でも非常に優れたパフォーマンスを発揮します。その技術パラメータは非常に競争力があり、CV 値は 0.08 で正確に制御されています。最大入力圧力の 1.5 倍の安全マージンにより、高圧環境での長期間の動作が確実に保証され、0.9kg の軽量設計により、柔軟なパネルまたは壁への取り付けが可能になります。

  • 説明
  • お問い合わせ

シリーズ

ボディポート

入口圧力

出口圧力

ゲージ

インレットコネクタ

コンセントコネクタ

オプション

SR1

B

D

F

G

00

00

P

SR1L

(316L)

SR1B

(スチール電気メッキ)

A

B

D

G

J

M

Q

C:4000psi

D:3000psi

F:500psi

F:0-500psi

G:0-250psi

1:0-100psi

K:0-50psi

L:0-25psi

Q:30'HgVac-30psi

S:30'HgVac-60psi

T:30"HgVac-100psi

U:30"HgVac-200psi

G:MPa表

P: psi/バーテーブル

W:圧力計なし

00:1/4"NPT(F)

01:1/4"NPT(M)

23:CGA330

24:CGA350

27:CGA580

28:CGA660

30:CGA590

52:G5/8"-RH(F)

63:W21.8-14RH(F)

64:W21.8-14LH(F)

他の形式のコネクタも利用可能です

選択

00:1/4"NPT(F)

01:1/4"NPT(M)

10: 1/8 インチカードスリーブコネクタ

11: 1/4 インチカードスリーブコネクタ

12: 3/8 インチカードスリーブコネクタ

15: 6mmカードスリーブコネクタ

16: 8mmカードスリーブコネクタ

74:M8×1RH(M)

他の形式のコネクタも利用可能です

選択

P:パネル取り付け

R:安全弁

N:ニードルバルブ

D: ダイヤフラムバルブ
